N870

Technical details

Last updated on 22-10-2026 12:46

Hardware

N870 Multicell system:

Up to 250 users / SIP accounts / DECT handsets
1 to 60 base stations
Up to 10 simultaneous G.711 calls per base (8 G.729 Calls or 5 G.722 Calls)
Seamless handover and roaming
Ethernet RJ45 10/100 Mbps
Integrated power over Ethernet
Wall mountable
One hardware which can be switched to roles: Integrator / DECT Manager / DECT Base

With Virtual Integrator

Up to 20000 users / SIP accounts / DECT handsets
Up to 6000 base stations

Software:

Up to 60 parallel calls per N870 Multicell system
Exceptional HD sound with HDSP
DECT high security standard STEP B
Security: TLS 1.3, SRTP, SIPS, HTTPS
Easy setup and configuration
LDAP(S) Directories (up to 10)
XML Directories
Auto-provisioning (HTTP(s)/TR-069 on demand)
IPUI based handset registration
Sync over the air (DECT) and Sync over LAN (PTPv2), also mixed
Firmware update, file based, scheduled
SUOTA (Push)
Alarm messaging and Location with external alarm servers
CrewPTT
Provisioning of connected DECT devices

Small system: 1-10 base-stations, 50 handsets and 20 simultaneous calls. (DECT manager is also a DECT base and in this mode it supports 5 concurrent calls when 1 or max 9 base station(s) are connected, without base stations it supports 8 concurrent calls)

Medium system: 11-60 base-stations, 250 handsets and 60 simultaneous calls. (Due to capacity, DECT manager is only a manager. Switching between Medium and Small is costing you one additional device.)

Large system: Up to 4 multi-cell DECT Managers, 20 single-cell DECT Managers, 240 base-stations, 800 handsets and 240 simultaneous calls. N870 in role integrator only is needed.

Enterprise system: Up to 100 multi-cell DECT Managers, 300 single-cell DECT Managers, 6000 base-stations, 20000 handsets and 6000 simultaneous calls. Virtual Integrator is needed.
