N870 Integrator
Integrator
The Integrator is a software that combines multiple N870 and/or N670 systems to one large DECT system.
It is available in 2 versions.
Virtual Integrator
- Integrator software: Can be downloaded from this wiki
- An Virtual integrator license is needed, without a license it can be used for 35 days
- Hardware (Not delivered by Gigaset): FAQ - Integrator
- Capacity:
- Up to 100 Multi-cell DECT managers (N870 DM or N670 with upgrade license)
- Up to 300 Single-cell N670 devices
- Up to 6000 DECT base-stations (60 per Multi-cell DM)
- Up to 20000 DECT handsets
- Up to 6000 simultaneous calls
N870 in integrator role only
- A normal N870 device can be switched to role integrator only
- No license is needed
- Hardware: A (normal) N870 device
- Capacity:
- Up to 4 Multi-cell DECT managers (N870 DM or N670 with upgrade license)
- Up to 20 Single-cell N670 devices
- Up to 240 DECT base-stations (60 per Multi-cell DM)
- Up to 800 DECT handsets
- Up to 240 simultaneous calls
Licensing
To use the Integrator, you need a license.
The following licenses are available.
License | Order number |
|---|---|
N870 Virtual Integrator software License (Not needed if the N870 is used as Integrator → role integrator only) | S30852-H2716-X1 |
Multi-cell DECT manager License (N870 DECT Manager / N670 with multi-cell License) | S30852-H2716-X2 |
N670 DECT Manager license | S30852-H2714-X2 |
N670 upgrade to N870 feature level | S30852-H2714-X3 |
See this page with more info about Licensing: N870 Integrator Licensing
