FAQ - Lookup caching
Valid for: | N530 | N610 | N670 | N770 | N870 | N870E | Embedded Integrator | Virtual Integrator |
Introduction
When using the phonebook lookup feature, by default with every incoming call the device will do a phonebook lookup to match the incoming number with a name.
This can cause load on the server hosting the phonebooks. To reduce the load and have a faster name presentation we have the following options.
- From software 2.52: If CNIP is available do not start a lookup
- Caching with the options listed below
CNIP has priority over lookup
From software 2.52 we have implemented that if CNIP information is available, we do not do an Lookup.
This can be disabled via:
- Auto-provisioning
- Web-interface (Software 2.57.0 or higher)
Provisioning
<provisioning version="1.1" productID="e2">
<nvm>
<!-- 1 = Enabled (Default), 0 = Disabled -->
<param name="DmGlobal.0.CNIPOverAutolookup" value="0" />
</nvm>
</provisioning>
Web-interface:
In the web-interface go to: Settings - Mobile devices - Administration
Caching
Parameter | |
|---|---|
Netdir.<x>.CachingType For value x see: FAQ - Directories number list | |
Example for LDAP (x=0): <param name="Netdir.0.CachingType" value="1"/> | |
Value | |
0 | Buffer entries (For cache size see below) |
1 | ask every lookup (Default) |
2 | refresh after 15 minutes |
3 | refresh after 1 hour |
4 | refresh after 6 hour |
5 | refresh after 12 hour |
6 | refresh after 18 hour |
7 | refresh after 1 day |
8 | refresh after 2 days |
9 | refresh after 3 days |
10 | refresh after 5 days |
11 | refresh after 1 week |
The Cache Size is default 100 entries.
Parameter | |
|---|---|
DmGlobal.0.LookupCacheSize | |
<param name="DmGlobal.0.LookupCacheSize" value="100"/> | |
0 | Minimum Value |
100 | Maximum Value |
